W139 - BLDC Motors

W139 - BLDC Motors

- Steel case BLDC motor design

- Electrical erosion resistant bearing

- IP20/IP44 protection

- Optional built-in or external control

- Programmable speed control (Analog/PWM): 200~3000rpm

- Multiple input voltage models: 155Vdc(110Vac), 310Vdc(220Vac)

- Safety functions: under-voltage, over-voltage, over-current, over-temp


Application:
Fresh Air Units, Fan Coil Units

Model

type

ZWM139-0250-10D

ZWM139-0375-10D

ZWM139-0560-10D

ZWM139-0750-10D

Input Voltage

[Vdc]

155/310

155/310

155/310

155/310

Rated Speed

[rpm]

800

850

1050

1200

Output Power

[W]

250

375

560

750

Motor Poles

num.

8/10

8/10

8/10

8/10

Motor Efficiency

[%]

84

85

86

87

Insulation Class

type

B

B

B

B
